Fig. 1

ID

ZDB-IMAGE-110207-20

Genes

Publication

Du et al., 2011 - Rumba and Haus3 are essential factors for the maintenance of hematopoietic stem/progenitor cells during zebrafish hematopoiesis

All Figures

Figures for Du et al., 2011


Figure Caption

Fig. 1 rumba^hkz1 and samba^hkz2 are defective in definitive hematopoiesis. (A-B′) WISH of rag1 expression in 6 dpf wild-type (WT) zebrafish siblings (A,A′) and rumba^hkz1-/- (B) and samba^hkz2-/- mutants (B′). The red circles indicate the position of the thymus. (C-F′) WISH of αe1-globin (C-D′) and mpo (E-F′) in 22 hpf wild-type siblings (C,C′,E,E′) and rumba^hkz1-/- (D,F), and samba^hkz2-/- mutants (D′,F′). (G-J′) WISH of αe1-globin (G-H′) and mpo (I-J, I′-J′) in 6 dpf wild-type siblings (G,G′,I,I′) and rumba^hkz1-/- (H,J) and samba^hkz2-/- mutants (H′,J′). Insets in G-J′ show enlarged details of the CHT region. The blue arrowheads indicate the position of the kidney.

Figure Data

Expression / Labeling details

Phenotype details
