Fig. 3 - Supplemental 1 Analysis of proliferation and apoptosis in the OPs of sly mutants and control siblings. (A-D’) Immunostaining for Phospho-histone H3 (magenta) to label dividing cells on Tg(neurog1:GFP) embryos (green) at 16 hpf and 21 hpf (A-B’ show images at 21 hpf, dorsal view), and on Tg(omp:meYFP) embryos (green) at 28 and 36 hpf (C-D’ show images at 36 hpf, frontal view). In A-B’ the OP is surrounded by a dotted line. Arrows = instances of Phospho-histone H3 positive cells in the placodal Tg(neurog1:GFP)+ or Tg(omp:meYFP)+ clusters. (E–H) Number of Phospho-histone H3 positive cells in the OP at 16 hpf (n=19 controls; n=8 mutants), 21 hpf (n=21 controls; n=6 mutants), 28 hpf (n=8 controls; n=7 mutants) and 36 hpf (n=9 controls; n=9 mutants) in control embryos and sly mutants. Unpaired, two-tailed t test. (I-L’) Immunostaining for Activated Caspase 3 (magenta) to label apoptotic cells/debris on Tg(neurog1:GFP) embryos (green) at 16 hpf and 21 hpf (I-J’ show images at 21 hpf, dorsal view), and on Tg(omp:meYFP) embryos (green) at 28 and 36 hpf (K-L’ show images at 36 hpf, frontal view). In I-J’ the OP is surrounded by a dotted line. Arrows = instances of Activated Caspase 3 positive cells or debris in the OP or in contact with the placodal Tg(neurog1:GFP)+ or Tg(omp:meYFP)+ clusters. (M–P) % of left OPs with zero, one or two and more Activated Caspase 3 positive cells or debris in the OP or very close to the OP at 16 hpf (n=25 controls; n=9 mutants), 21 hpf (n=25 controls; n=9 mutants), 28 hpf (n=8 controls; n=10 mutants) and 36 hpf (n=10 controls; n=10 mutants) in control embryos and sly mutants. Chi2 test. (Q, R) Total number of YFP+ cells in control and mutant Tg(omp:meYFP)+ OPs at 28 hpf (Q) and 36 hpf (R) (n=3 control placodes; n=3 mutant placodes for each stage). Unpaired, two-tailed t test.
Figure Caption
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Elife
