Fig. 7
Prazosin alleviates the motor phenotype induced by sqstm1 knockdown in zebrafish
(A) Schematic illustration of zebrafish treatment and functional assessment.
(B) Quantification of swimming parameters in embryos injected with control or sqstm1-specific AMO, either untreated or treated with prazosin for 3 days, using a ViewPoint system. The qualitative scores ranged from 0 to 5. Data are presented as mean ± SEM from three independent experiments. Statistical significance was determined using the chi-square test for contingency data. ∗∗∗∗p ≤ 0.0001.
(C) Representative western blot images and corresponding quantification of SQSTM1 and ACTB expression in embryos injected with control or sqstm1-specific AMO, with or without prazosin treatment for 3 days. Data are presented as mean ± SEM from four technical replicates. Statistical significance was determined using one-way ANOVA with Dunnett’s post hoc test and Student’s t test. ∗p ≤ 0.05.
