Fig. S7
Reduced exdpf Specifically Increases p21 Expression in the Pancreatic Area In situ hybridization using a p21 probe. (A) A control embryo injected with standard morpholino control. Note p21 expression in the head area. No p21 expression is detected in the pancreatic area. (B) An embryo injected with exdpf mRNA (100 pg). Note p21 expression in the head area. No p21 expression is detected in the pancreatic area. (C) An embryo injected with exdpf morpholino. Note p21 expression in the pancreatic area (arrow). |
