FIGURE

Figure 1

ID

ZDB-FIG-231113-22

Publication

Belcher et al., 2023 - The zebrafish paralog six2b is required for early proximal pronephros morphogenesis

Other Figures

All Figure Page

Back to All Figure Page

Figure 1

Early expression of six2a and six2b paralogs. (a, c, e, g) Whole mount in situ hybridization for six2a. Expression is detected in the developing head and otic vesicles. Focal expression was observed adjacent to the pronephric tubule at 24 hpf (arrowhead in g). (b, d, f, h) Whole mount in situ hybridization for six2b. Expression was detected in the intermediate mesoderm and otic vesicles. At 18 somites, weak signal could be detected in the pronephric tubules. By 24 hpf six2b was predominantly found in cells adjacent to the tubule epithelium (arrowhead in h). Head is toward the left in all images. IM, intermediate mesoderm; OT, otic vesicle; P, pronephros.

Expression Data

Genes:	six2a six2b
Fish:	AB
Anatomical Terms:	head intermediate mesoderm otic vesicle pronephric tubule
Stage Range:	10-13 somites to Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Sci. Rep.
