Figure 4 - Supplement 2
- ID
- ZDB-IMAGE-240307-1
- Genes
- Publication
- Shi et al., 2023 - Single-cell transcriptomic profiling of the zebrafish inner ear reveals molecularly distinct hair cell and supporting cell subtypes
- All Figures
- Figures for Shi et al., 2023
|
Figure Caption
Figure 4 - Supplement 2 dla labels putative hair cell progenitors in the cristae and maculae. HCR in situ hybridization of 5 dpf zebrafish. Maximum intensity projections of (A) posterior crista (lateral view), (B) utricle (dorsal view), and (C) saccule (lateral view) showing dla expression in a subset of support cells (arrowheads) peripheral to myo6b+hair cells. Scale bars = 10 μm.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Elife
