Fig. 5

Paraxial FGF Signaling Is Maintained in ntl/bra Embryos

(A–P) pea3 and (Q–T) fgf8 expression at the indicated stages in uninjected and MO2-injected wild-type siblings and ntl mutants. Embryos are shown from an (A–D) animal view with dorsal to the right, (E–H) vegetal view with dorsal to the right, and (I–T) posterior view with dorsal to the top. Arrow marks the posterior notochord.

Expression Data

Genes:	etv4 fgf8a
Fish:	WT tbxta^b195/b195 WT + MO2-tbxtb tbxta^b195/b195 + MO2-tbxtb
Knockdown Reagent:	MO2-tbxtb
Anatomical Terms:	axial mesoderm margin paraxial mesoderm
Stage Range:	Shield to Bud

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
