Fig. 7

Dpysl3 is ubiquitously expressed in both the central and peripheral axons of RB neurons. A–F: Localization of Dpysl3-mCherry (A–C) and mCherry (D–F) (red) in the cell body of RB neurons. RB neurons were visualized using zCREST2 HSP70:GFP transgenic line (green). Arrows, nuclei of RB neurons. Dorsal views with anterior at top. G–I: Localization of Dpysl3-mCherry in RB neurons (red) at 28 hpf. RB neurons were visualized using zCREST2 HSP70:GFP transgenic line (green). Red arrowheads, central axon; blue arrowheads, peripheral axons. Lateral views with anterior at right.

Expression Data

Gene:	GFP
Fish:	rw011aTg
Anatomical Term:	Rohon-Beard neuron
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
