FIGURE

Fig. 7

ID

ZDB-FIG-250204-7

Publication

Xiao et al., 2025 - Hsf1 is essential for proteotoxic stress response in smyd1b-deficient embryos and fish survival under heat shock

Other Figures

All Figure Page

Back to All Figure Page

Fig. 7

Hsf1 is required for the upregulation of hsp40, hspa1b and hspa8b gene expression in response to heat shock of zebrafish embryos. Wild type and hsf1?/? mutant zebrafish embryos of 24 hpf were exposed to heat shock at 37.5�C for 1 h. Compared to the control groups (A?F) without heat shock treatment, expression of hsp40, hspa1b and hspa8b mRNAs was significantly upregulated in the heat shock treated WT embryos (G?I). However, this heat shock response of upregulating these hsp gene expression was blocked in hsf1?/? mutant embryos (J?L). Scale bar = 100 ?m.

Expression Data

Genes:	dnaja hsp70.3 hspa1b hspa8b
Fish:	WT hsf1^mb30/mb30 hsf1^mb31/mb31 hsf1^mb32/mb32
Condition:	heat shock
Anatomical Term:	whole organism
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	hsf1^mb30/mb30 hsf1^mb31/mb31 hsf1^mb32/mb32
Condition:	heat shock
Observed In:	whole organism
Stage:	Prim-5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ FASEB J.
