FIGURE 1

Expression of adap1 during early embryogenesis. (a–c) Embryos stained with the adap1 sense probe (a: Lateral view) and the adap1 antisense probe (b: Lateral view, c: Dorsal view) at 32 hpf. (d–f) Embryos stained with the adap1 sense probe (d: Lateral view) and the adap1 antisense probe (e: Lateral view, f: Dorsal view) at 48 hpf. (g–i) Embryos stained with the adap1 sense probe (g: Lateral view) and the adap1 antisense probe (h: Lateral view, i: Dorsal view) at 72 hpf. Expression of adap1 was widely detected in the forebrain, midbrain and hindbrain at 32 hpf. Expression of adap1 in the midbrain, and hindbrain was maintained at 48 hpf and 72 hpf. Scale bar, 200 μm (a).

Expression Data

Gene:	zgc:92360
Fish:	WT
Anatomical Terms:	forebrain hindbrain midbrain
Stage Range:	Prim-15 to Protruding-mouth
